Kyocera ECOSYS M3540dn Service Manual

2NM/2NX/2NY/2NZ/2P0/2P6-1
2-1-12
1. Paper feed clutch (PFCL) ..................... Primary paper feed from cassette.
2. Registration clutch (RCL)...................... Controls the secondary paper feed.
3. Duplex clutch (DUCL) *2....................... Controls the drive of the duplex feed roller.
4. Middle clutch (MIDCL) *2 ...................... Controls the paper conveying at the conveying section.
5. Developer clutch (DEVCL).................... Controls the drive of the developer.
6. MP solenoid (MPSOL) .......................... Controls the MP bottom plate.
7. Faceup solenoid (FUSOL) *2................ Operates the feedshift guide.
8. Cleaning lamp (CL) ............................... Eliminates the residual electrostatic charge on the drum.
9. Fuser heater 1 (FUH1).......................... Heats the heat roller.
10. Fuser heater 2 (FUH2) *2 ..................... Heats the heat roller.
11. Fuser thermostat 1 (FUTS1) ................. Prevents overheating of the heat roller.
12. Fuser thermostat 2 (FUTS2) *2............. Prevents overheating of the heat roller.
List of correspondences of other names
*1: 40 ppm model only, *2: 50/60 ppm model only
No. Name used in service manual Name used in parts list Part.No.
1 Paper feed clutch (PFCL)
PARTS CLUTCH 20-2W Z35R
(RARTS DRIVE FEED ASSY SP)
-
(302LV94251)
2 Registration clutch (RCL)
CLUTCH 50 Z35R 302KV44041
3 Duplex clutch (DUCL) *2
PARTS CLUTCH 20-2W Z35R -
4 Middle clutch (MIDCL) *2
PARTS CLUTCH 20-2W Z35R
(RARTS DRIVE FEED ASSY SP)
-
(302LV94251)
5 Developer clutch (DEVCL)
PARTS CLUTCH 20-2W Z35R 302VL94161
6 MP solenoid (MPSOL)
SOLENOID MPF
(RARTS DRIVE FEED ASSY SP)
-
(302LV94251)
7 Faceup solenoid (FUSOL) *2 SOLENOID EXIT -
8 Cleaning lamp (CL)
P.W.BOARD ASSY ERASER
(DK-3100(U)) *1
(DK-3100(E)) *1
(DK-3100(AO)) *1
(DK-3130(U)) *2
(DK-3130(E)) *2
(DK-3130(AO)) *2
-
(302MS93042)
(302MS93022)
(302MS93052)
(302LV93062)
(302LV93042)
(302LV93072)
9 Fuser heater 1 (FH1) HEATER LAMP 120 *1
(FK-3100(U)) *1
HEATER LAMP 240 *1
(FK-3100(E)) *1
HEATER LAMP 120 *2
(FK-3130(U)) *2
HEATER LAMP 240 *2
(FK-3130(E)) *2
-
(302MS93094)
302L244030
(302MS93074)
302LV44020
(302LV93132)
302LV44031
(302LV93112)
10 Fuser heater 2 (FH2) *2
11 Fuser thermostat 1 (FTS1) THERMAL-CUTOUT 202 FUSER
(FK-3100(U)) *1
(FK-3100(E)) *1
(FK-3130(U)) *2
(FK-3130(E)) *2
-
(302MS93094)
(302MS93074)
(302LV93132)
(302LV93112)
12 Fuser thermostat 2 (FTS2) *2

Kyocera ECOSYS M3540dn Specifications

General

Print Technology	Laser
Print Resolution	1200 x 1200 dpi
Duplex Printing	Yes
Scan Type	Color CIS
Scan Resolution	600 x 600 dpi
Fax Capability	Yes
Fax Transmission Speed	33.6 kbps
Paper Capacity	500 sheets
Connectivity	USB, Ethernet
Copying	Yes
Scanning	Yes
Modem Speed	33.6 kbps
Standard Input Capacity	500 sheets
Standard Output Capacity	250 sheets
Maximum Output Capacity	250 sheets
Maximum Print Size	A4
Standard Interfaces	USB 2.0, Ethernet
Ethernet LAN	Yes
Internal Memory	512 MB
Power Consumption (typical)	661 W
Display	LCD
Functions	Print, Copy, Scan, Fax
Operating System Compatibility	Windows, Mac OS, Linux
Print Speed	40 ppm (pages per minute)
Copy Speed	40 cpm (copies per minute)
Standard Paper Tray Media Types	Recycled
Maximum Internal Memory	1, 536 MB
Weight	22 kg
Product Colour	Black
