Kyocera ECOSYS M3540dn Service Manual

2NM/2NX/2NY/2NZ/2P0/2P6
2-2-19
*1: 50/60 ppm model only
YC4
1 LFANN - 0/24 V DC LFM: On/Off
Connected to
the LSU fan
motor
2 +24V0_E3 O 24 V DC 24 V DC power output
YC7
1 +3.3V2_E2 O 3.3 V DC 3.3 V DC power output
Connected to
the waste
toner sesor
2 WTLEDN I 0/3.3 V DC WTS(LED): On/Off
3 WTSENS I Analog WTS output signal
4 +3.3V2_E2 O 3.3 V DC 3.3 V DC power output
YC8
1 +3.3V1_E1 O - 3.3 V DC power output
Connected to
the MP paper
sesor
2 GND - - Ground
3 MPFSENS I 0/3.3 V DC MPS: On/Off
YC9 *1
1 3.3V2_E2 O 3.3 V DC 3.3 V DC power output
Connected to
the duplex
sesor 1
2 GND - - Ground
3 DUJAMSEN1
N
I 0/3.3 V DC DUS: On/Off
YC10 *1
1 REARSWN I 0/3.3 V DC RECSW: On/Off
Connected to
the right
cover switch
2 GND - - Ground
YC11 *1
1 ENVMOT O 0/5 V DC ENVM: On/Off
Connected to
the envelope
motor
2 GND - - Ground
YC12
1 OUTB3 O 0/3.3 V DC EM B3 drive control signal
Connected to
the eject
motor
2 OUTB1 O 0/3.3 V DC EM B1 drive control signal
3 OUTA3 O 0/3.3 V DC EM A3 drive control signal
4 OUTA1 O 0/3.3 V DC EM A1 drive control signal
YC13 *1
1 FACEUDRN O 0/24 V DC FUSOL: On/Off
Connected to
the faceup
solenoid
2 +24V2_E2 O 24 V DC 24 V DC power output
3 FACEDDRN O 0/24 V DC FUSOL: On/Off
Connector Pin Signal I/O Voltage Description

Kyocera ECOSYS M3540dn Specifications

General

Print Technology	Laser
Print Resolution	1200 x 1200 dpi
Duplex Printing	Yes
Scan Type	Color CIS
Scan Resolution	600 x 600 dpi
Fax Capability	Yes
Fax Transmission Speed	33.6 kbps
Paper Capacity	500 sheets
Connectivity	USB, Ethernet
Copying	Yes
Scanning	Yes
Modem Speed	33.6 kbps
Standard Input Capacity	500 sheets
Standard Output Capacity	250 sheets
Maximum Output Capacity	250 sheets
Maximum Print Size	A4
Standard Interfaces	USB 2.0, Ethernet
Ethernet LAN	Yes
Internal Memory	512 MB
Power Consumption (typical)	661 W
Display	LCD
Functions	Print, Copy, Scan, Fax
Operating System Compatibility	Windows, Mac OS, Linux
Print Speed	40 ppm (pages per minute)
Copy Speed	40 cpm (copies per minute)
Standard Paper Tray Media Types	Recycled
Maximum Internal Memory	1, 536 MB
Weight	22 kg
Product Colour	Black
