(3) Connector lists
Connector Pin Signal I/O Voltage Description
YC1
1 DEEP_SLEEP
N
I 0/3.3 V DC Sleep signal
Connected to
the control
PWB
2 RFANH I 0/24 V DC RFM: On/Off
3 MPFSOL I 0/24 V DC MPSOL: On/Off
4 COVOPN I 0/3.3 V DC ILSW: On/Off
5 LIFTMOTOR I 0/5 V DC LM: On/Off
6 RFANL I 0/24 V DC RFM: On/Off
7 FEEDCLN I 0/24 V DC PFCL: On/Off
8 DLPCL I 0/3.3 V DC DEVCL: On/Off
9 DHEATER_R
EM
I 0/24 V DC DH: On/Off
10 POWERSW O 0/3.3 V DC PSSW: On/Off
11 REGCL I 0/24 V DC RCL: On/Off
12 CASSET I Analog CSSW: On/Off
13 PSLEEPN O 0/5 V DC Sleep mode signal
14 MMOTCWN I 0/5 V DC MM drive shift signal
15 RELAY O 0/5 V DC Relay control
16 MMOTRDYN O 0/3.3 V DC MM ready signal
17 ZCROSSN I 0/5 V DC(pulse) Zero crossing signal
18 MMOTON I 0/5 V DC MM: On/Off
19 HEAT1REM I 0/24 V DC Fuser heater control
20 TYPE - - Not used
21 GND - - Ground
22 MMOTCLK O 0/5 V DC(pulse) MM clock signal
23 *1 GND - - Ground
24 *1 DMOTCLK O 0/5 V DC(pulse) DRM clock signal
25 *1 GND - - Ground
26 *1 DMOTRDYN I 0/3.3 V DC DRM ready signal
27 *1 MIDCL O 0/24 V DC PCCL: On/Off
28 *1 DMOTON O 0/5 V DC DRM: On/Off
29 *1 DUCL O 0/24 V DC DUCL: On/Off
30 *1 HEAT2REM O 0/24 V DC Fuser heater control
To Next Page
