Kyocera ECOSYS M3540dn Service Manual

2NM/2NX/2NY/2NZ/2P0/2P6
2-2-30
*1: 50/60 ppm model only
YC9 *1
1 LIFTMOTOR O 0/5 V DC LM: On/Off
Connected to
the lift motor
2 GND - - Ground
YC10
1 MMOTCW O 0/5 V DC MM drive shift signal
Connected to
the main
motor and
the durm
motor
2 MMOTRDYN I 0/3.3 V DC MM ready signal
3 MMOTCLKN O 0/5 V DC(pulse) MM clock signal
4 MMOTONN O 0/5 V DC MM: On/Off
5 GND - - Ground
6 +24V2_E1 O 24 V DC 24 V DC power output
7 *1 +24V2_E1 O 24 V DC 24 V DC power output
8 *1 GND - - Ground
9 *1 DMOTONN O 0/5 V DC DRM: On/Off
10 *1 DMOTCLKN O 0/5 V DC(pulse) DRM clock signal
11 *1 DMOTRDYN I 0/3.3 V DC DRM ready signal
12 *1 DMOTCW O 0/5 V DC DRM rotation direction
YC11
1 +24V2_E1 O 24 V DC 24 V DC power output
Connected to
the MP sole-
noid
2 MPFSOLN O 0/24 V DC MPSOL: On/Off
YC12
1 +24V2_E1 O 24 V DC 24 V DC power output
Connected to
the devel-
oper clutch,
feed clutch,
regist clutch,
mid clutch
and duplex
clutch
2 DLPCLN O 0/3.3 V DC DEVCL: On/Off
3 +24V2_E1 O 24 V DC 24 V DC power output
4 FEEDCLN O 0/24 V DC PFCL: On/Off
5 +24V2_E1 O 24 V DC 24 V DC power output
6 REGCLN O 0/24 V DC RCL: On/Off
7 *1 +24V2_E1 O 24 V DC 24 V DC power output
8 *1 MIDCLN O 0/24 V DC PCCL: On/Off
9 *1 +24V2_E1 O 24 V DC 24 V DC power output
10 *1 DUCLN O 0/24 V DC DUCL: On/Off
Connector Pin Signal I/O Voltage Description

Kyocera ECOSYS M3540dn Specifications

General

Print Technology	Laser
Print Resolution	1200 x 1200 dpi
Duplex Printing	Yes
Scan Type	Color CIS
Scan Resolution	600 x 600 dpi
Fax Capability	Yes
Fax Transmission Speed	33.6 kbps
Paper Capacity	500 sheets
Connectivity	USB, Ethernet
Copying	Yes
Scanning	Yes
Modem Speed	33.6 kbps
Standard Input Capacity	500 sheets
Standard Output Capacity	250 sheets
Maximum Output Capacity	250 sheets
Maximum Print Size	A4
Standard Interfaces	USB 2.0, Ethernet
Ethernet LAN	Yes
Internal Memory	512 MB
Power Consumption (typical)	661 W
Display	LCD
Functions	Print, Copy, Scan, Fax
Operating System Compatibility	Windows, Mac OS, Linux
Print Speed	40 ppm (pages per minute)
Copy Speed	40 cpm (copies per minute)
Standard Paper Tray Media Types	Recycled
Maximum Internal Memory	1, 536 MB
Weight	22 kg
Product Colour	Black
