Kyocera FS-1030D

2G6
2-3-6
Connector Pin No. Signal I/O Voltage Description
YC1
Connected
to the main
PWB
YC3
Connected
to the
registration
solenoid
YC4
Connected
to the main
motor
YC5
Connected
to the
eraser lamp
YC6
Connected
to the laser
scanner
unit
YC7
Connected
to the MP
paper
sensor
YC9
Connected
to the MP
feed
solenoid
1 RSTN O 0/5 V DC Reset signal: Reset/Normal
2 SGND - Ground Ground
3 EGIRN O 0/5 V DC Engine interrupt request signal
4 SDIR O 0/5 V DC Serial line direction signal
5 SBSY O 0/5 V DC Serial line busy signal
6 PDMASKN O 0/5 V DC PDN mask signal
7 EGSI I 0/5 V DC Engine serial input data signal
8 SCKN I 0/5 V DC (pulse) Serial clock signal
9 EGSO O 0/5 V DC Engine serial output data signal
10 PLGCLK I 0/5 V DC (pulse) Polygon motor clock signal
11 SGND - Ground Ground
12 OUTPEN O 5 V DC Video data output enable signal
13 +5V1 O 5 V DC 5 V DC power supply for main PWB
14 +5V1 O 5 V DC 5 V DC power supply for main PWB
15 +5V1 O 5 V DC 5 V DC power supply for main PWB
16 SGND - Ground Ground
1 +24V3 O 24 V DC 24 V DC power supply for registration solenoid
2 RESDRN O 0/24 V DC Registration solenoid: On/Off
1 FEDDRN O 0/24 V DC Paper feed solenoid: On/Off
2 PFSEN I 0/5 V DC Optional paper feeder: Installed/Not installed
3 PFPERN I 0/5 V DC Paper sensor (Optional paper feeder): On/Off
4 PFCLK O 0/5 V DC (pulse) Paper feed motor (Optional paper feeder) clock
signal
5 PFMDRN O 0/5 V DC Paper feed motor (Optional paper feeder): On/Off
6 PGND - Ground Ground
7 +5V O 5 V DC 5 V DC power supply for main motor and optional
paper feeder
8 MRDRN O 0/5 V DC Main motor ready signal: Ready/Not ready
9 MOTRN O 24 V DC Main motor: On/Off
10 +24V3 O 24 V DC 24 V DC power supply
1 ERASPW O 24 V DC 24 V DC power supply for eraser lamp
2 ERASER O 0/24 V DC Eraser lamp: On/Off
1 PLGCLK O 0/5 V DC (pulse) Polygon motor clock signal
2 PLGRDYN I 0/5 V DC Polygon motor ready signal: Ready/Not ready
3 PLGDRN O 0/5 V DC Polygon motor: On/Off
4 PGND - Ground Ground
5 +24V3 O 24 V DC 24 V DC power supply for laser scanner unit
1 +5V O 5 V DC 5 V DC power supply for MP paper sensor
2 HANDSN I 0/5 V DC MP paper sensor: On/Off
3 SGND - Ground Ground
1 +24V3 O 24 V DC 24 V DC power supply for MP feed solenoid
2 MPFSOL O 0/24 V DC MP feed solenoid: On/Off
