Kyocera FS-1030D

2G6
2-3-7
Connector Pin No. Signal I/O Voltage Description
YC10
Connected
to the
waste toner
sensor
YC11
Connected
to the bias
PWB
YC12
Connected
to the bias
PWB
YC13
Connected
to the
switchback
solenoid
YC14
Connected
to the paper
sensor
1 +5V O 5 V DC 5 V DC power supply for waste toner sensor
2 TNFULL I 0/5 V DC Waste toner sensor: Toner Full/Normal
3 SGND - Ground Ground
1 SGND - Ground Ground
2 SGND - Ground Ground
3 SGND - Ground Ground
4 +5V O 5 V DC 5 V DC power supply
5 +5V O 5 V DC 5 V DC power supply
6 +5V O 5 V DC 5 V DC power supply
7 HVCLK O 0/5 V DC (pulse) Developing bias output clock signal
8 ZCROSS I 0/5 V DC (pulse) Zero cross signal
9 MHVDR2 O 0/5 V DC Main charger output control 2: On/Off
10 EXITN I 0/5 V DC Exit sensor: On/Off
11 PSEL1 O 0/5 V DC Transfer bias output control signal: On/Off
12 SLEEP O 0/5 V DC Sleep mode control signal: On/Off
13 +5V O 5 V DC 5 V DC power supply
14 HVISEL O 0/5 V DC Transfer bias (current) control signal: On/Off
15 HEATN O 0/24 V DC Heater lamp: On/Off
16 RTHVDR O 0/5 V DC Transfer bias (reverse) control signal: On/Off
1 THERM I Analog Fuser thermistor temperature detection signal
2 THVDR O 0/5 V DC Transfer bias: On/Off
3 FAN1 O 0/12/24 V DC Cooling fan rotation: High/Low/Stop
4 FAN2 O 0/24/24 V DC Cooling fan rotation: Half/High/Stop
5 MHVDR1 O 0/5 V DC Main charger output control signal 1: On/Off
6 +24V2 O 24 V DC 24 V DC power supply
7 TONER I 0/5 V DC Toner sensor detection signal: Normal/Empty
8 RESIT I 0/5 V DC Registration sensor: On/Off
9 SWIN I 0/5 V DC Cassette switch: On/Off
10 PGND - Ground Ground
11 PGND - Ground Ground
12 +24V3 O 24 V DC 24 V DC power supply
13 +24V3 O 24 V DC 24 V DC power supply
1 DUDR1 O 0/24 V DC Switchback solenoid: On/Off
2 COMMON O 24 V DC 24 V DC power supply
3 DUDR2 O 0/24 V DC Switchback solenoid: On/Off
1 +5V O 5 V DC 5 V DC power supply for paper sensor
2 PAPER I 0/5 V DC Paper sensor: On/Off
3 GND - Ground Ground
