1-3-7
2G6
Figure 1-3-12
1. Pull the cassette out of the printer.
2. Set the paper in the cassette.
Figure 1-3-13
Load paper.
Cassette
1. Turn on the printer's power switch. Upon turning
on the power, the printer's 4 indicators flash in
sequence until printer initialization is complete,
then the indicator [on line] lights steadily.
2. The printer can print two different types of status
page standard and service-purpose. A service-
purpose status page contains more detailed
information about printer settings than a standard
status page.
To print a standard status page, press
the GO key for at least 3 seconds and
the indicators light in sequence from
top to bottom.
To print a service-purpose status
page, press the GO key for more than
10 seconds and the indicators light in
sequence twice from top to bottom.
Initializing the printer and make test print (status page).
Power switch
GO key
