Kyocera FS-1030D

2G6
1-4-6
Service items Description










Items
PWB mask version
Operation panel PWB
mask version
BROM version
Software jumper switch
information (hexadeci-
mal)
[First byte/second byte
(displayed in OEM mode
only)]
Main PWB mask version
Main PWB firmware re-
lease date
Total page counter
Drum serial number
Printer serial number
Paper Jam Log
Description
[Engine mask version/Engine software version]
First byte
bit 0 = 1: (Fixed)
bit 1 = 0: Overseas, 1: Domestic (Japan)
bit 2, 3 (Not used)
bit 4 = 0: Kyocera, 1: OEM
bit 5 = 0: For Europe, 1: For US
bit 6 = 0: Non MICR mode, 1: MICR mode
bit 7 (Not used)
Second byte: Displayed in OEM mode only
#
Remembers 1 to 8th
of occurrence. If the
occurrence of the pre-
vious paper jam is
less than 8, all of the
paper jams are
logged.
When the occurrence
exceeds 8, the oldest
occurrence is re-
moved.
Count.
The total page count
at the time of the pa-
per jam.
Event
Log code (2 digit, hexa-
decimal, 6 categories)
(a) Cause of a paper
jam
(b) Detail of paper
misfeed location
(c) Detail of paper
source
(d) Detail of paper size
(e) Detail of paper type
(f) Detail of paper exit
location
Refer to the next page
for the details of each
log code.
