2G6
1-6-16
6. Remove the engine PWB (See page 1-6-9).
7. Remove wires from wire saddles on the cord cover.
8. Remove one screw.
9. Remove the cord cover.
Figure 1-6-17 Removing the cord cover
Wire saddle
Wire saddles
Cord cover
Screw
