Firmware 03.00 - DMS EN 5.0 - 07/2009 L 221
8400 BaseLine D | Software Manual
Parameter reference
Table of attributes
C00158 Cause of controller inhibit 24417 5F61 E 1 UNSIGNED_16 ;
C00159
Cause of quick stop QSP 24416 5F60 E 1 UNSIGNED_16 ;
C00165
Error information 24410 5F5A A 1 VISIBLE_STRING ;
C00166
Error information text 24409 5F59 A 3 VISIBLE_STRING ;
C00168
Error number 24407 5F57 A 8 UNSIGNED_32 1 ;
C00169
Time of error 24406 5F56 A 8 UNSIGNED_32 1 ;
C00170
Error counter 24405 5F55 A 8 UNSIGNED_8 1 ;
C00173
Mains voltage 24402 5F52 E 1 UNSIGNED_8 1 ;;;
C00174
Reduced brake chopper threshold 24401 5F51 E 1 UNSIGNED_8 1 ;;
C00177
Switching cycles 24398 5F4E A 2 UNSIGNED_32 1 ;
C00178
Elapsed-hour meter 24397 5F4D E 1 UNSIGNED_32 1 ;
C00179
Power-on time meter 24396 5F4C E 1 UNSIGNED_32 1 ;
C00182
S-ramp time PT1 24393 5F49 E 1 INTEGER_16 100 ;;
C00200
Firmware product type 24375 5F37 E 1 VISIBLE_STRING ;
C00201
Firmware compile date 24374 5F36 E 1 VISIBLE_STRING ;
C00203
Product type code 24372 5F34 A 9 VISIBLE_STRING ;
C00222
L_PCTRL_1: Vp 24353 5F21 E 1 INTEGER_16 10 ;;
C00223
L_PCTRL_1: Tn 24352 5F20 E 1 UNSIGNED_16 1 ;;
C00224
L_PCTRL_1: Kd 24351 5F1F E 1 UNSIGNED_16 10 ;;
C00225
L_PCTRL_1: MaxLimit 24350 5F1E E 1 INTEGER_16 100 ;;
C00226
L_PCTRL_1: MinLimit 24349 5F1D E 1 INTEGER_16 100 ;;
C00227
L_PCTRL_1: acceleration time 24348 5F1C E 1 UNSIGNED_32 1000 ;;
C00228
L_PCTRL_1: deceleration time 24347 5F1B E 1 UNSIGNED_32 1000 ;;
C00231
L_PCTRL_1: Operating range 24344 5F18 A 4 INTEGER_16 100 ;;
C00234
Oscillation damping influence 24341 5F15 E 1 UNSIGNED_16 100 ;;
C00242
L_PCTRL_1: operating mode 24333 5F0D E 1 UNSIGNED_8 1 ;;
C00243
L_PCTRL_1: Acceleration time influ-
ence
24332 5F0C E 1 UNSIGNED_32 1000 ;;
C00244
L_PCTRL_1: Deceleration time influ-
ence
24331 5F0B E 1 UNSIGNED_32 1000 ;;
C00245
L_PCTRL_1: PID output value 24330 5F0A E 1 INTEGER_16 100 ;
C00443
DIx: Level 24132 5E44 A 2 UNSIGNED_16 ;
C00444
DOx: Level 24131 5E43 A 2 UNSIGNED_16 ;
C00470
LS_ParFree_b 24105 5E29 A 16 UNSIGNED_8 1 ;;
C00472
LS_ParFree_a 24103 5E27 A 4 INTEGER_16 100 ;;
C00480
LS_DisFree_b 24095 5E1F E 1 UNSIGNED_8 ;
C00481
LS_DisFree 24094 5E1E A 4 UNSIGNED_16 ;
C00482
LS_DisFree_a 24093 5E1D A 4 INTEGER_16 100 ;
C00516
Checksums 24059 5DFB A 1 UNSIGNED_32 1 ;
C00517
User menu 24058 5DFA A 20 INTEGER_32 1 ;;
C00565
Resp. to mains phase failure 24010 5DCA E 1 UNSIGNED_8 1 ;;
C00574
Resp. to brake resist. overtemp. 24001 5DC1 E 1 UNSIGNED_8 1 ;;
C00581
Resp. LS_SetError_x 23994 5DBA A 2 UNSIGNED_8 1 ;;
C00598
Resp. to open circuit AINx 23977 5DA9 A 1 UNSIGNED_8 1 ;;
C00600
Resp. to DC bus undervoltage 23975 5DA7 A 1 UNSIGNED_8 1 ;;
C00601
Del.resp. to fault: DC bus overvoltage 23974 5DA6 A 1 UNSIGNED_16 1000 ;;
C00604
Resp. to device overload (Ixt) 23971 5DA3 E 1 UNSIGNED_8 1 ;;
C00606
Resp. to motor overload (I²xt) 23969 5DA1 E 1 UNSIGNED_8 1 ;;
C00620
16-bit system connection 23955 5D93 A 12 UNSIGNED_16 1 ;;
C00621
Bool system connection 23954 5D92 A 23 UNSIGNED_16 1 ;;
C00700
LA_NCtrl: analog connection list 23875 5D43 A 9 UNSIGNED_16 1 ;;
C00701
LA_NCtrl: digital connection list 23874 5D42 A 18 UNSIGNED_16 1 ;;
Code Name Index Data Access
dec hex DS DA DT Factor R W CINH
