LNC-Lathe New T6-Series
CNC Operation
LNC Technology Co., Ltd. 57
【Column Description】
※ Working Method List：display a list of 14 types working methods as below show:
⊙ Drilling：drilling one internal hole on the material
⊙ ORR：outer rough diameter. Cutting most of material part that is made by straight line and arch. Tool
moving direction is according to the perpendicular Z-axis direction
⊙ ORA：outer stock removal in turning. Clearing the most material part that is made by line and arch. Tool
moving direction is according to the perpendicular X-axis direction.
⊙ ORP：outer pattern repeating. Clearing the most material of the pattern that is made by straight line and
arch. Tool moving direction is according to the curve outline.
⊙ IRR：internal rough diameter. Cutting most of material part that is made by straight line and arch. Tool
moving direction is according to the perpendicular Z-axis direction.
⊙ IRA：internal stock removal in turning. Clearing the most material part that is made by line and arch.
Tool moving direction is according to the perpendicular X-axis direction.
⊙ IRP：internal pattern repeating. Clearing the most material of the pattern that is made by straight line
and arch. Tool moving direction is according to the curve outline.
⊙ IF：internal finishing cycle. Clearing the rest of the material of the outline that is combined by straight line
and arch.
⊙ OF：outer finishing cycle. Clearing the rest of the material of the outline part that is combined by straight
line and arch.
⊙ OGOV：grooving on outer surfaces,. Using grooving tool to cut a concave shape on the working piece.
Outer surface, inter surface or end-faces is according to the grooving position.
⊙ IGOV：grooving on internal surface. Using grooving tool to cut a concave shape on the working piece.
Outer surface, inter surface or end-faces is according to the grooving position.
⊙ FGOV：grooving on end faces. Using grooving tool to cut a concave shape on the working piece. Outer
surface, inter surface or end-faces is according to the grooving position.
⊙ OSEW：external thread cutting. Cutting thread horizontally and selecting feeding method according to
the using method.
⊙ ISEW：internal thread cutting. Cutting thread horizontally and selecting feeding method according to the
using method.
