LNC T6 Series User Manual

LNC-Lathe New T6-Series
CNC Operation
LNC Technology Co., Ltd. 63
【Column Description】
※ Procedure：display the currently editing procedure order number.
※ Working Method：display the working name of the currently editing procedure.
※ Tool NO.：display the selected tool NO. of the currently editing procedure. 4 types of tool NO. Type A for
drilling tool, Type B for pattern tool, Type C for grooving tool, and Type D for thread tool. The
number should be the tool NO. from the tool clear list of the screen.
※ Cutting Parameter Column：the needed key-in column will be difference due to different working methods.
⊙ START：0.
⊙ END：all linear and arch numbers of profile.
⊙ ORG X：0.
⊙ ORG Z：0.
⊙ ST X：material at the upper right point is the diameter coordinate.
⊙ ST Z：material at the upper right point is the Z coordinate
⊙ DEP. X：lathe cutting depth
⊙ WID. Z：lathe cutting width.
⊙ COUNT: lathe-cutting repetitive times.
⊙ RES X：lathe-cutting preservation amount.
⊙ RES Z：0
⊙ AMOUNT: lathe-cutting escape amount.
⊙ TIME: drilling dwell time.
⊙ TYPE: the lathe-cutting mode selection.
⊙ DRILL: pre-drilling of internal lathe-cutting.
【Function keys at Screen Bottom】
※ Return: switch to the main function screen.
【Function Keys at Right of Screen】
None.
