Installation Guide
6. Place a point on the image at a well recognizable object on the picture by
a single left click! You can move the point by another single click.
7. Find the same point on the map as well and designate it by a single left
click!
8. Now move the crosshair of the PTZ exactly to the same point which
you've designated before on the panoramic image! Use the left mouse
button to move the crosshair!
9. If you find the same points on the panoramic image, on the PTZ image
and on the map as well, click on the Save button or use the Ctrl+S
hotkey! After that the point turns to yellow. If you do not want to save
the points, click on Cancel!
10. To delete a Guidance point, activate the D icon on the panoramic
image, select the point you want to delete by clicking on it (the point
turns to pink). If you click between the points the program will choose
the closest point to the place of the clicking. You can change between
the points, using the arrow icons in the lower right corner of the image.
Left click again on the point to delete it! After deleting, click on the Save
button!
11. To modify a point, activate the M icon on the panoramic image
and select the point you want to modify by clicking on it! If you click
between the points the program will choose the closest point to the
place of the clicking. After you have selected the point you can replace it
by single left clicks. You can change between the points, using the arrow
icons in the lower right corner of the image. After modifying, click on the
Save button!
12. If you have created, modified or deleted a point accidentally, you
can use the ESC key to undo your last action.
13. Create at least six point-pairs with this method for each Logipix PTZ
camera. Try to create the points forming triangle shapes (place them as
they would be the apexes of triangles), and avoid to place all of them on
one common line. More Reference points mean more accuracy.
69/80
