LPKF ProtoMat S63 - Type Label; Scope of Delivery

Product description ProtoMat S
10 HB V0.9/Mrz-11 © 2011 LPKF AG
1
Pos: 2 /ED_Technische_D okumentation/2_Bedi enungsanleitung/ Maschine/RP_Fr äsbohrplotter/Pr otoMat_S_Serie/Pr otoMat_S_Serie_IIG/ Kapitel_1_Produktb eschreibung/1_2_ Typenschild @ 0\mod_125 4482520905_2058. docx @ 3583 @ 2
1.2 Type label
The type label is located at the right side of the machine housing besides the
mains switch.
If any questions occur concerning identification of your machine and the
corresponding equipment please always quote the serial number according to
the type label to the LPKF service.
Pos: 3 /ED_Technische_D okumentation/2_Bedi enungsanleitung/ Maschine/RP_Fr äsbohrplotter/Pr otoMat_S_Serie/Pr otoMat_S_Serie_IIG/ Kapitel_1_Produktb eschreibung/1_3_Li eferumfang @ 0\mod_1 254483397197_2058. docx @ 3587 @ 23344
1.3 Scope of delivery
The scope of delivery of the ProtoMat S Series includes:
Tab. 1: Scope of
delivery
Quantity Description
1 ProtoMat S series, inclusive sound proof housing
1 Power cable with safety plug (230 V AC), length 1,5 m
1 Power cable with US plug (115 V AC), length 1,5 m
1 USB connection cable, 5 m
1 Drill underlay material with the dimensions 229 x 305 mm (9 x 12“)
1 Base material FR4 with the dimensions 229 x 305 mm (9 x 12“)
1 Tool set with:
2 Reference hole stripes
5 Reference hole pivots (3 x 8 mm)
1 Force fitting tool for reference hole pivots
4 Fuses 10 A (T10L 250 V)
2 Reference hole drill, spiral drill 2.95 mm
1 Fixing tape (to be dissolved residual-free)
1 Maintenance and service set
1 Solder Paste cartridge for machines with dispense set
1 CD-ROM
1 Software CircuitPro
1 Set of operation manuals, consisting of
1 Operating manual CircuitPro
1 Operating manual ProtoMat S
Fig. 2: Type plate
/1/ Machine type /4/ Operating voltage
/2/ Serial number /5/ Mains frequency in Hz
/3/ Year of production /6/ Power consumption in VA
1
2
3
4
5
6
