3.4 Technical Data
3.4.1 ProtoMat S43
Technical data circuit board plotter type ProtoMat S43:
Tab. 6: Technical
data ProtoMat
S43
Data Values
Mains power supply Voltage range from 110 to 240 V AC, 50 - 60 Hz
Power consumption 200 W
Weight Appr. 58 kg
Dimension 670 x 540 x 760 mm (W x H x D)
Permissible ambient temperature Range from 15 to 25 °C
Permissible atmospheric humidity Up to 60 %
Workplace noise level 71 dB (A), devoid of noise level dust extraction
Motor mill/drill head Three phase motor
Range of speeds Up to 40,000 min
-1
(variable)
Processing speed 150 mm/s
Drilling capacity 150 strokes per minute
Tool change mechanism Manually
Number of tools Up to 15, software limit
Tool collet base 3.175 mm (1/8“)
Motor X-axis Three phase stepping motor
Motor Y-axis Three phase stepping motor
Motor Z-axis Two phase stepping motor
Milling depth adjustment Manually
Working area for work table 305 x 229 x 5 mm (X x Y x Z)
Working area for vacuum table 305 x 229 x 25 mm (X x Y x Z)
Resolution (X/Y) +/- 1 µm (0.04 Mil)
Repeat accuracy +/- 5 µm (0.2 Mil)
Exactness reference hole system +/- 20 µm (0.8 Mil)
Minimal drill diameter 0.2 mm
