ProtoMat S Functional description
© 2011 LPKF AG HB V0.9/Mrz-11 35
3
3.4.2 ProtoMat S63
Technical data circuit board plotter type ProtoMat S63:
Tab. 7: Technical
data ProtoMat
S63
Data Values
Mains power supply Voltage range from 110 to 240 V AC, 50 - 60 Hz
Power consumption 200 W
Weight Appr. 58 kg
Dimension 670 x 540 x 760 mm (W x H x D)
Permissible ambient temperature Range from 15 to 25 °C
Permissible atmospheric humidity Up to 60 %
Workplace noise level 71 dB (A), devoid of noise level dust extraction
Motor mill/drill head Three phase motor
Range of speeds Up to 60,000 min
-1
(variable)
Processing speed 150 mm/s
Drilling capacity 150 strokes per minute
Tool change mechanism Automatically
Number of tools Up to 15 tool holder positions, software limit
Tool collet base 3.175 mm (1/8“)
Motor X-axis Three phase stepping motor
Motor Y-axis Three phase stepping motor
Motor Z-axis Two phase stepping motor
Milling depth adjustment Automatically
Working area work table 305 x 229 x 38 mm (X x Y x Z)
Working area vacuum table 305 x 229 x 25 mm (X x Y x Z)
Resolution (X/Y) +/- 0.25 µm (0.01 Mil)
Repeat accuracy +/- 5 µm (0.2 Mil)
Exactness reference hole system +/- 20 µm (0.8 Mil)
Minimal drill diameter 0.2 mm
