Operation ProtoMat S
48 HB V0.9/Mrz-11 © 2011 LPKF AG
6
Pos: 20 /ED_Technisc he_Dokumentation/2_Be dienungsanleitun g/Maschine/RP_Fräsb ohrplotter/Pr otoMat_S_Serie/Pr otoMat_S_Serie_II G/Kapitel_6_Bedien ung/6_02_01_System _starten @ 0\mod_1254904 224405_2058.doc x @ 3675 @ 23
6.2 Start system
Always proceed in the same sequence when starting the system.
Note
The dust extraction is connected to the circuit board plotter
via a control cable and is operating automatically. The dust
extraction will be activated and deactivated by the circuit
board plotter.
■ System start
1. Check all connection cables and tubes.
➨ Exchange damaged cables or tubes at once.
2. Open the soundproof hood of the soundproof housing.
3. Switch on the circuit board plotter by setting the main switch to position 1
(ON).
4. Start the PC by setting the main switch to position 1 (ON).
5. Enter user name and password. Wait until the operation system has
booted the user interface.
6. Go to the task bar and click on Start>Programs>LPKF Laser &
Electronics>CircuitPro.
➨ The CircuitPro start-up logo is shown:
Fig. 17: Startup
♦ CircuitPro starts and establish the connection to the circuit board plotter.
