10.1.2.2 Multilayer-Material
Tab. 20:
Multilayer
material
Material Dimensions
(mm)
Copper
(µm)
Quan-
tity
Order
code.
Thin laminate 104 ML
with protective foil for
galvanics
229 x 305 x 0,2 -/5 1 119 571
Prepeg Typ 2125 275 x 200 x 0,1 / 2 119 572
Base material FR4 229 x 305 x 1,0 18/18 1 119 574
Base material 104 ML 229 x 305 x 0,36 18/18 1 119 575
Thin laminate 104 ML
without protective foil for
ProConduct
229 x 305 x 0,2 -/18 1 119 818
Pressing plate with
reference holes
229 x 205 x 1,6 / 1 120 345
Press cushion with
reference holes
229 x 305 x 1,7 / 1 120 999
