6.2.3.5 Head actions
Fig. 27: Various
/1/ Lift mill/drill head up/down /3/ Exhaust unit on/off
/2/ Motor on/off
The individual buttons have the following functions:
No. Description
/1/ Click [Lift head up/down] to lower the mill/drill head.
/2/ Click [Motor on/off] to start or stop the motor.
The symbol changes correspondingly from a green triangle (90°
position) to a red rectangle.
/3/ Click [Exhaust unit on/off] to activate/deactivate the exhaust unit by
operator.
The symbol changes correspondingly from a green triangle (90°
position) to a red rectangle.
