LPKF ProtoMat S63 - Mill;Drill Head; Protomat S43

ProtoMat S Functional description
© 2011 LPKF AG HB V0.9/Mrz-11 29
3
3.2.3 Mill/drill head
3.2.3.1 ProtoMat S43
Fig. 8: Mill/drill
head
ProtoMat S43
/1/ Status LED /4/ Milling depth adjustment (manual)
/2/ Manual Z direction adjustment /5/ Open/close collet chuck (manual)
/3/ Tool holder
Tab. 5: LED
signalling
ProtoMat S43
LED Signal
ON The circuit board plotter is ready for operation.
1
2
3
4
5
