Operation ProtoMat S
86 HB V0.9/Mrz-11 © 2011 LPKF AG
6
2. Click the input field \Save in\ and select the destination folder.
3. Click the input field \File name\ and edit the new file name.
4. Click [Save].
♦ The production data is saved in a new file.
6.10.2 Exit CircuitPro
When exit CircuitPro the mill/drill head and the working table are moving to the
zero position.
■ Exit CircuitPro
1. Click File>Exit.
♦ CircuitPro is terminated.
6.10.3 Switch off the circuit board plotter
Note
Always wait until the mill/drill head and the working table have
reached their reference position.
■ Switch off the circuit board plotter
1. Open the soundproof hood.
2. Set the main switch of the circuit board plotter to position 0 (OFF).
3. Close the soundproof hood.
♦The circuit board plotter is switched off.
6.10.3.1 Shutdown and switch off the PC
Note
Of course the PC can be left in action whenever the PC is used for
other applications.
■ Shutdown the PC
1. Click Start>Shut down.
2. Wait until the PC is completely shut down and set the main switch of the
PC in position OFF (0).
♦ The PC is switched off.
6.10.4 Switch off the dust extraction
Note
The dust extraction has only to be switched off if the system
operates in continuous running mode.
In automatic mode the dust extraction is switched on/off via the
circuit board plotter.
■ Switch off the dust extraction
1. Turn the main switch of the dust extraction to position OFF (0).
♦ The dust extraction is switched off.
