ProtoMat S Operation
© 2011 LPKF AG HB V0.9/Mrz-11 73
6
Pos: 28 /ED_Technisc he_Dokumentation/2_Be dienungsanleitun g/Maschine/RP_Fräsb ohrplotter/Pr otoMat_S_Serie/Pr otoMat_S_Serie_II G/Kapitel_6_Bedien ung/6_08_Automatikb etrieb @ 0\mod_12549 04474284_2058.doc x @ 3691 @ 233343
6.8 Automatic mode
Note
Every individual tool for the PCB production must be clamped into
the mill/drill head manually, if a circuit board plotter without
automatic tool change function is used.
During automatic operation single or multilayer PCBs are produced semi-
automatically. According to the prepared CBF file the tools are selected and the
drill holes and milling paths are produced.
ATTENTION
Health hazard!
During machining of work pieces harmful fine particles and
gases may occur which can be inhaled!
Make sure that the dust extraction is activated during machining
of the work piece. Be sure to use fine particle filters exclusively.
ATTENTION
Risk of injury!
During the machining process the used tools and the collet
chuck heat up, direct contact may cause burnings.
Wear protective gloves and tweezers for manual change of tools
during operation.
ATTENTION
Risk of injury!
The used tools are sharp-edged and cause cut or stab wounds
when used improperly.
Store the tools always in the toolbox and secure the toolbox
against unauthorised utilisation.
