Maintenance/servicing ProtoMat S
90 HB V0.9/Mrz-11 © 2011 LPKF AG
8
Pos: 33 /ED_Technisc he_Dokumentation/2_Be dienungsanleitun g/Maschine/RP_Fräsb ohrplotter/Pr otoMat_S_Serie/Pr otoMat_S_Serie_II G/Kapitel_8_Inst andhaltung_Wartung/ 8_2_Wartung @ 0\mod_125 4838907429_2058.doc x @ 3656 @ 2
8.2 Maintenance
For proper function of the circuit board plotter maintenance activities have to be
carried out in certain intervals.
ATTENTION
Risk of injury!
Unintended starting of the motor and moving of the mill/drill
head during repairs or maintenance may cause severe injuries.
Make sure that only one person operates the machine. Protect
the machine against unauthorised usage during maintenance
and repair activities.
ATTENTION
Risk of injury!
The opened hood of the soundproof housing may shutdown and
crush finger or the whole hand.
Open the hood of the soundproof housing always up to the
latching position and protect the machine against shocks.
Tab. 15:
Maintenance and
service plan
Component Interval/Control Maintenance activity
Milling depth limiter after 100 operating
hours
cleaning
Chucks after 100 operating
hours
cleaning
Tool position Tool is not put down
correctly
Configure tool position
Dust extraction Extraction power
decreases perceptible
Exchange fine particle filter
