3 Functional description
In the following chapter the function of the circuit board plotter is described in
detail.
3.1 Function
The circuit board plotter ProtoMat S is employed for processing of electrical
printed circuit boards. Printed circuit boards can consist of several layers
(multilayer) and may have up to six layers. In addition the ProtoMat S can be
employed for processing of signs or housing components (front plate).
The circuit board plotter can be used for the following machining processes:
● Milling and drilling of single or double sided base material
● Milling and drilling of multilayer materials
● Milling of SMD soldering paste stencils
● Milling of solder resist masks
● Engraving of signs or housing plates
● Milling of cut-outs and outlines
● Perforating of planar materials
3.1.1 Permitted machining materials
For reliable and safe operation of the circuit board plotter ProtoMat S we
recommend original LPKF consumables. These articles are available with good
value as multilayer sets or they are sold as single material for the different
applications.
Tab. 4: Machining materials
Designation Contents Usage
FR4 base material,
copper-clad
FR4 base material 1,5 mm, 229 x
305 mm (9 x 12“), with or without
protective foil, 3 mm reference
hole drillings
Production of single or double sided
circuit boards
Multilayer set Base material, surface laminate,
prepreg, seal rings
Production of multilayer circuit boards
i.e. further processing with the LPKF
multilayer press Multipress S
Drilling underlay Drilling underlay, format DIN A4, 2
mm
Protection of the working table during
drilling or during material penetrating
drilling
Sinter plate Air permeable sinter plate for
vacuum table (optional)
Work plate or drilling underlay for the
vacuum table (optional)
Cleaning pad Metal-free cleaning pads Removal of oxidation remains on
copper coatings
