ProtoMat S Troubleshooting
© 2011 LPKF AG HB V0.9/Mrz-11 87
7
7 Troubleshooting
This chapter gives some information concerning correction of small faults that
may occur during operation of the circuit board plotter.
Note
Please contact the LPKF service if the measures described in
this chapter do not provide the desired success. LPKF is not
liable for improper repairs!
Tab. 14: Trouble
shooting
Fault Cause Remedy
No connection No power supply Check the mains cable and insert the
mains plug into the socket if necessary.
Click [Connect].
Main switch of the circuit
board plotter is in position
OFF
Set the switch to position ON.
Click [Connect].
No data transmission Check the USB cable between plotter and
PC. Fix the connector plug or exchange the
USB cable.
Click [Connect].
Check the USB settings of the operating
system.
Click [Connect].
No dust extraction No power supply Check the mains cable and insert the
mains plug into the socket if necessary.
Main switch of the dust
extraction is in position OFF
Set the operation mode switch to either ON
or AUTOMATIK.
Fuse triggered
Press the Reset Button of the dust
extraction.
No data transmission Check the USB cable between circuit
board plotter and dust extraction. Fix the
connector plug or exchange the cable.
Tool uptight Position of the tool holder is
incorrect
Import the tool holder position again.
Tool was not correctly
inserted into the tool holder
Insert the tool with its top down into the tool
holder until it stops.
Tool holder soiled Clean the tool holder.
Collet chuck soiled Clean the collet chuck.
