LPKF ProtoMat S63 - Working Area

Functional description ProtoMat S
28 HB V0.9/Mrz-11 © 2011 LPKF AG
3
3.2.2 Working area
Fig. 6: Working
table
/1/ Mill/drill head /2/ Working table
Fig. 7: Vacuum
table
/1/ Mill/drill head /4/ Connector
/2/ Vacuum table /5/ Pressure meter
/3/ Vacuum control unit
2
1
1
2
3
4
5
