6 Operation
The following chapter describes production processes that you can carry out
with the circuit board plotter.
CircuitPro basic knowledge is required.
6.1 Production process
The production process has always three phases:
Phase I System start
The circuit board plotter, the PC and the dust extraction have to
be activated and the control software CircuitPro has to be
started.
Phase II Execute the production mode
Corresponding to the requirements for production of the material
the machining mode, e.g. manual drilling, manual milling or
automatically operation has to be selected. During automatically
mode the individual production phases are selected manually
and will be executed by the circuit board plotter.
Phase III System shut down
The control software CircuitPro has to be terminated and the
circuit board plotter, the PC and the dust extraction must
switched off.
