LPKF ProtoMat S63 - Tool Set 1;8

A
ppendix ProtoMat S
94 HB V0.9/Mrz-11 © 2011 LPKF AG
10
Tab. 16: Tools
Tool specification Length
(mm)
Ø
(mm)
Order
code.
Spiral Drill, cylindrical, 1/8“ 38 1,50 115 860
Spiral Drill, cylindrical, 1/8“ 38 1,60 115 861
Spiral Drill, cylindrical, 1/8“ 38 1,70 115 862
Spiral Drill, cylindrical, 1/8“ 38 1,80 115 863
Spiral Drill, cylindrical, 1/8“ 38 1,90 115 864
Spiral Drill, cylindrical, 1/8“ 38 2,00 115 865
Spiral Drill, cylindrical, 1/8“ 38 2,10 115 866
Spiral Drill, cylindrical, 1/8“ 38 2,20 115 867
Spiral Drill, cylindrical, 1/8“ 38 2,30 115 868
Spiral Drill, cylindrical, 1/8“ 38 2,40 115 869
Spiral Drill, cylindrical, 1/8“ 38 2,95 115 870
Spiral Drill, cylindrical, 1/8“ 38 3,00 115 871
Furthermore LPKF offers tool sets.
10.1.1.1 Tool set 1/8“
Order code: 115 909
Tab. 17: Tool set
1/8“
Tool specification Length
(mm)
Ø
(mm)
Quan-
tity
End Mill, cylindrical, PCB/Aluminium, 1/8“ 36 1,00 2
End Mill, cylindrical, PCB/Aluminium, 1/8“ 36 2,00 1
Contour Router, special tool, cylindrical, 1/8“ 38 1,00 1
Contour Router, special tool, cylindrical, 1/8“ 38 2,00 1
Spiral Drill, cylindrical, 1/8“ 38 0,60 5
Spiral Drill, cylindrical, 1/8“ 38 0,70 5
Spiral Drill, cylindrical, 1/8“ 38 0,80 5
Spiral Drill, cylindrical, 1/8“ 38 1,00 5
Spiral Drill, cylindrical, 1/8“ 38 1,10 2
Spiral Drill, cylindrical, 1/8“ 38 1,20 2
Spiral Drill, cylindrical, 1/8“ 38 1,50 2
Spiral Drill, cylindrical, 1/8“ 38 3,00 2
