ProtoMat S Functional description
© 2011 LPKF AG HB V0.9/Mrz-11 31
3
Fig. 10: Tool
holder unit
/1/ Tool holder /2/ Tool (e. g. Spiral drill 0.2 mm)
Fig. 11: Camera
/1/ Camera /3/ Connector for dispenser
/2/ Ring light /4/ Objective
1
2
1
4
2
3
