Genral information
Procedure descriptions
For this manual step by step procedures or
workflows are compiled to operation sequen-
ces. An individual operation sequence
consists of at least three components
Title+Step+ Result.
Component Description
■ Title
Short description of the
expected result – charac-
terized with a prefixed “■“.
1. Step A consecutively numbered
order of the individual work
item of the described
procedure.
➨ Partial
result
Partial result of an operation
step. The operation sequence
is continuously progressed.
♦ Result
Result of the operation
sequence - characterized with
a prefixed “♦“.
Symbols and signal words
Inside this document the following symbols
will be used to indicate important information:
Symbol Description
Safety instruction
WARNING – dangerous hazard
to people
ATTENTION – a machine
damage is possible
Note
The note will be used for any
information about the optimal
solution for a realisation of a
specific function or operation.
Note
The memo will be used for any
additional information about a
function or operation step.
© Copyright
® Registered Trademark
Registered trademark
The LPKF logo and the LPKF product names
are registered trademarks of LPKF Laser &
Electronics AG.
Microsoft and Windows are brand names or
registered trademarks of the Microsoft Cor-
poration in USA and/or international.
All other brand names belong to the respec-
tive owner.
Standards
The following standards and guidelines had
been pursued for the creation of this
document:
Standard Description
DIN 5008
05-2005
Rules for writing and layouting
VDI 4500
Bl.1,2
11-2006
Technical documentation -
Definitions and legal basics
IEC 62079
11-2001
Preparation of instructions -
Structuring, content and
presentation
ISO 12100-2
02-2003
Safety of machinery - Basic
concepts, general principles for
design - Part 2: Technical
principles
DIN EN
60204
01-2006
Safety of machinery - Electrical
equipment of machines - Part 1:
General requirements
