LPKF ProtoMat S64 - Protective Devices

ProtoMat S64/S104
Safety
V. 1.0 | LPKF Laser & Electronics AG
21/160
Figure
Description
The fuse (1) protects against excessive electrical current.
Table 1: Safety devices
1.9 Protective devices
This chapter describes the safety devices of the system and how they work. They
serve to guarantee a safe and trouble-free system operation of the system.
Fig. 2: Limit switch for deactivating the axis movement when the cover is opened
Figure
Description
The limit switch is for monitoring the cover. If the cover is opened
during operation, the axes of the processing head and of the
vacuum table are switched off. The tool spindle is brought to
standstill.
Table 2: Safety devices
