3.8 Software
The system software CircuitPro PM is used for preparing and converting the PCB
layout data into a compatible file format (e.g. the LMD format), for further editing the
data, and for controlling the system.
The system software imports your CAD data, aperture tables, and tool lists. The
design rule check checks the conductive track width and the conductive track spacing,
and lists the inconsistencies in the Message pane. At the same time, these are
displayed graphically in the CAM view. Thus, you can correct the data before starting
the actual production process. Additionally, the software serves as automated control
of the system and enables direct access to all operation parameters.
For a detailed description of the system software refer to the software manual.
The following system requirements have to be met in order to install CircuitPro PM
successfully:
Component
Minimum system requirements
CPU
2 GHz
LPKF discourages the use of the following CPU because it causes
problems:
 Intel Xeon
RAM
2 GB
Memory requirements
2 GB
Graphics board
With 128 MB dedicated memory (non-shared memory)
LPKF discourages the use of the following graphics boards
because they cause problems:
 Intel 82945G
Screen resolution
1024 x 768 pixels
USB port
2 x USB 2.0
Supported operating
systems
Windows 7 (64bit)
Table 10: Minimum system requirements
Component
Recommended system configuration
CPU
Dual Core, 2.6 GHz
LPKF discourages the use of the following CPU because it causes
problems:
 Intel Xeon
RAM
8 GB
Memory requirements
2 GB
Graphics board
With 1 GB dedicated memory (non-shared memory)
LPKF discourages the use of the following graphics boards
because they cause problems:
 Intel 82945G
Screen resolution
1680 x 1050 pixels
USB port
2 x USB 2.0
Supported operating
systems
Windows 7 (64bit), Windows 10 (64bit)
Table 11: Recommended system configuration
