ProtoMat S64/S104
Structure and function
V. 1.0 | LPKF Laser & Electronics AG
29/160
3.4 System components
This chapter describes the components of the system. First of all, make yourself
familiar with the individual components of the system before starting the operation.
Before operating the system, also inform yourself about the important software
elements and the different operation modes.
3.4.1 Total view
The following figures show the system and its components with closed and opened
acoustic hood.
Fig. 4: Front view with closed acoustic hood
1 Acoustic hood
2 Handle
2
1
