LPKF Laser & Electronics AG | V. 1.0
Messages present statistical information of the
program. These can be feedback of CircuitPro
PM on certain actions that have been
executed, e.g.: “New document ... created”.
The messages can be displayed or hidden by
clicking on [Messages].
Service messages are displayed when
maintenance of the system is due. Contact the
LPKF Service.
The service messages can be displayed or
hidden by clicking on [Service].
Highlights the selected action in the CAM
view.
Example: You draw a rectangle. The
Message pane displays a corresponding
message (e.g. Rectangle Drawn_5 has been
created). If you activate [Raise selection] and
click on the message, the rectangle is
highlighted in the CAM view.
Table 18: Pane Messages
8.2 Actions in case of an error
If a malfunction has occurred, you can contact the LPKF Service. You can create a
support information (only S104) via the menu Machining so that the service technician
can help you quickly. This zip file generated by the system contains, among others,
the occurred malfunctions and error codes. If you have configured sending e-mails
from the system software as well, you can send the support information to LPKF
directly via e-mail.
Clearing faults
1. Read the error description in the fault monitor.
2. Remedy the fault.
3. For a new initialization, acknowledge the fault if necessary.
The fault has been cleared.
If the faults still exist after initialization, restart the system software. If you have any
questions contact the LPKF Service.
