4.3 Unpacking the system
The following describes how to unpack the system. Observe also the unpacking
instructions.
WARNING
Risk of injury by heavy load!
The system is heavy and bulky and must not be lifted by one person. Incorrect lifting
can cause serious injuries, e.g. crushing injuries or spinal injuries.
 Always lift the system with four persons using the enclosed lifting device.
 Always wear the recommended safety shoes and protective gloves.
WARNING
Risk of injury by improper transport!
Incorrect transport using the enclosed lifting device can cause serious injuries. The
lifting device serves only for lifting and putting down the system.
 Transport the system only with a sufficiently load-bearing means of transport.
The system weighs 95 kg (~209.4 lbs) and has to be lifted by four persons using the
lifting device:
Fig. 22: System with lifting device
1 Foam damper
2 Steel rod
3 Transport sling
