3.5.3 Accessory kits
The following accessory kits are available:
Accessories kit ProtoMat S64 (order code: 10082407)
Quantity
Underlay Porex vacuum plate
5
Base material FR4, 229 mm x 305 mm (9 x 12 in), 0/35 µm,
thickness 1.5 mm, pre-drilled with 3 mm registration holes
10
Base material FR4, 229 mm x 305 mm (9 x 12 in), 35/35 µm,
thickness 1.5 mm, pre-drilled with 3 mm registration holes
5
Base material FR4, 229 mm x 305 mm (9 x 12 in), 18/18 µm,
thickness 1.5 mm, pre-drilled with 3 mm registration holes
5
Micro Cutter 1/8", 36 mm, d = 0.1 to 0.15 mm (orange)
5
End Mill 1/8", 36 mm, d = 1 mm (violet)
5
End Mill 1/8", 36 mm, d = 2 mm (violet)
2
End Mill 1/8", 38 mm, d = 1 mm (violet)
2
Special adhesive tape for fastening the base material
1
Tool set containing different tools
1
Reed switch for MultiPress
1
Table 4: Accessories kit S64
Accessories kit ProtoMat S104 (order code: 10086886)
Quantity
Underlay Porex vacuum plate
5
Base material FR4, 229 mm x 305 mm (9 x 12 in), 0/35 µm,
thickness 1.5 mm, pre-drilled with 3 mm registration holes
10
Base material FR4, 229 mm x 305 mm (9 x 12 in), 35/35 µm,
thickness 1.5 mm, pre-drilled with 3 mm registration holes
5
Base material FR4, 229 mm x 305 mm (9 x 12 in), 18/18 µm,
thickness 1.5 mm, pre-drilled with 3 mm registration holes
5
Micro Cutter 1/8", 36 mm, d = 0.1 to 0.15 mm (orange)
5
End Mill 1/8", 36 mm, d = 1 mm (violet)
5
End Mill 1/8", 36 mm, d = 2 mm (violet)
2
End Mill 1/8", 38 mm, d = 2 mm (green)
2
End Mill (RF) 1/8", 36 mm, d = 0.25 mm (blue), RF milling tools
10
End Mill (RF) 1/8", 36 mm, d = 0.15 mm (blue), RF milling tools
3
End Mill (RF) 1/8", 36 mm, d = 0.40 mm (blue), RF milling tools
3
Special adhesive tape for fastening the base material
1
Tool set containing different tools
1
Board cleaning pad
3
Table 5: Accessories kit S104
