LPKF ProtoMat S64 - Floor; The Systems Center of Gravity

First startup
ProtoMat S64/S104
66/160
LPKF Laser & Electronics AG | V. 1.0
5.2.4 Floor
The floor has to be leveled and antistatic and has to have a sufficient load-bearing
capacity for the total weight of the system (95 kg, ~209.4 lbs).
WARNING
Risk of injury by loss of stability!
Loss of stability due to an improper floor or missing locks can cause uncontrollable
movement or tipping of the system. This can cause serious injuries.
 Ensure that the floor has a sufficient load-bearing capacity for the system and is
even.
5.2.5 The system's center of gravity
The following figure shows the center of gravity of the system:
Fig. 38: Center of gravity of the system
