Tool check routines
In combination with the system software, the SX4 series offers the following tool check
routines that can be activated/deactivated in the menu Options:
 Collet check: This function checks whether there is a tool in the collet. For that,
the processing head moves to the area of the photo-interrupter.
 Tool holder check: This function checks whether there is a tool in a specific tool
holder. This check is executed with the camera.
 Tool position check: This function checks whether the tool is inserted correctly
into a specific tool holder. This check is executed with the camera.
3.5 Optional modules, accessories, extras
The system can be equipped with the following accessories:
 Tools (see product catalog)
 Extraction system with automatic on/off function
 230 V (order code: 116 666)
 110 V (order code: 115 974)
 Compressor for compressed-air production (order code: 10092064)
 Measuring microscope with 100x magnification, metric scale, and lighting (order
code: 10035579)
 Precision ring kit (order code: 116698)
 Stack light (order code: 10023555)
 Tool holder kit (order code: 10082398)
Refer to the product catalog to find a list of all tools and optional modules available.
For more information contact the LPKF sales department or your local representative.
