ProtoMat S64/S104
First startup
V. 1.0 | LPKF Laser & Electronics AG
75/160
Fig. 55: Connecting the USB cable to the PC

The USB cable has been connected.
5.4.5 Connecting the system to the mains power supply
The system is connected to the mains power supply using a mains cable.
Material
The following material is required:
Fig. 56: Mains cable
 Connecting the mains cable
CAUTION! Tripping hazard by hoses and cables!
Hoses and cables are routed to the system. If the hoses and cables are laid
inappropriately they pose a tripping hazard for the operating personnel.
 Always ensure that the hoses and cables do not pose a tripping hazard.
1. Connect the mains cable to the system.
2. Connect the mains cable to the earthed wall socket.
Ensure that the earthed wall socket is always accessible!

The mains cable has been connected.
