Structure and function
ProtoMat S64/S104
44/160
LPKF Laser & Electronics AG | V. 1.0
Figure
Description
table on or off.
The pressure gauge at the processing head (4) shows the
dispenser pressure that can be regulated with the rotary
control (5).
The pressure regulator for the dispenser (5) is at the
processing head. It is used for regulating the amount of
solder paste exiting the dispenser needle.
Table 9: Displays and control elements
