Technical data
ProtoMat S64/S104
24/160
LPKF Laser & Electronics AG | V. 1.0
Process data
Data
Value
Unit
Rotation speed range
S64: 10 000 to 60 000
S104: 10 000 to 100 000
min
-1
Max. structuring area (x/y/z)
305 × 229 × 8
(~12.0 x 9.0 x 0.3)
mm
(in)
Max. material dimensions (x/y/z)
330.5 × 249 × 8
(~13.0 x 9.8 x 0.3)
mm
(in)
Travel speed
150 (diagonally)
(5.9)
mm/s
(in/s)
Drilling performance
100 strokes
min
-1
Collet (1/8")
3.175 (0.125)
mm (in)
Resolution (x/y)
0.47 (0.02)
µm (mil)
Repeatability
± 5 (0.2)
µm (mil)
Accuracy of camera
1.8
(~0.07)
mm/pixel
(mil/pixel)
Emissions
Data
Value
Unit
Sound pressure level LpA (EN ISO 3744)
< 70
dB (A)
Sound power level LwA (EN ISO 3744)
< 70
dB (A)
EMC emission class
A
–
Extraction system
Data
Value
Unit
Extraction air flow
at least 186
m
3
/h
Extraction fitting (Ø)
50
mm
Separation efficiency
> 98 (≙ filter class: at least
E12)
%
