UM-1151140EN, Rev. C, May 2016
3.1.2.1.
Laser Console
3.1.2.2.
Remote Interlock
Connection Plug
3.1.2.3.
Footswitch
3.1.2.4.
Delivery Systems
The laser console houses the touch-screen control panel, laser emergency
stop button, control electronics, laser source with
associated optics and
power supply. The laser console is the central unit to
which the laser
components and delivery devices are attached.
The remote interlock plug must be inserted into the external interlock
connection port on the laser console’s rear panel for the laser to operate.
The plug may be wired to an external switch to disable the laser if the
treatment room doors are opened during treatment.
The footswitch activates the laser treatment beam when you press it while
the laser is in Ready mode. Three different types of footswitch are
available for the Smart532 system
1
:
●
Standard Footswitch – press the footswitch to emit laser energy.
●
Smart Footswitch – the Smart footswitch engages the automatic eye
safety filter when you place your foot inside of the footswitch housing
while the laser is in Ready mode.
●
PowerEase Footswitch – adjust the laser power by pressing the
switches on the inside left (decrease power) and right (increase power)
of the footswitch housing.
Delivery systems for a variety of applications may have been shipped with
your Smart532 laser system laser. Refer to the operator manuals included
with those delivery systems for specific descriptions and operating
instructions.
Compatible delivery systems include probes, fibers, laser indirect
ophthalmoscopes (LIO), LaserLinks and slit lamps.
1
Depending on the Lumenis purchase agreement.
