LUMENIS smart532 - 4.5.5. Eye Safety Filters; 4.5.5.1. Installing the Eye Safety Filter(s); 4.5.5.2. Connecting an Automatic Eye Safety Filter to the Laser; 4.5.5.3. Connecting a Fixed Eye Safety Filter to the Laser

4-10
UM-1151140EN, Rev. C, May 2016
Smart532
™
System Installation and Initial Setup
4.5.5. Eye Safety Filters
4.5.5.1. Installing the Eye
Safety Filter(s)
When using a LaserLink, a Lumenis slit lamp or Acculite delivery system,
you must install a compatible automatic or fixed eye safety filter onto the
slit lamp or operating microscope. The eye safety filter protects the
physician’s eyes from exposure to laser energy while looking through the
slit lamp or operating microscope.
If the eye safety filter is not properly connected to the Smart532 laser
system, or if the eye safety filter is not compatible with the system, an
error message will be displayed on the control panel.
Refer to the appropriate delivery system operator manual for detailed eye
safety filter installation instructions.
During treatment the eye safety filter must be attached to the slit
lamp or operating microscope. Failure to use an eye safety filter
could result in ocular injury. In addition some slit lamps and
microscopes require an auxiliary eye safety filter to protect
persons observing the procedure through an observation tube. To
determine if an auxiliary eye safety filter is required, review your
slit lamp or microscope operator’s manual or contact its
manufacturer.
4.5.5.2. Connecting an
Automatic Eye
Safety Filter to the
Laser
4.5.5.3. Connecting a Fixed
Eye Safety Filter to
When using an automatic eye safety filter, you must connect the eye safety
filter to the Smart532 laser system using the extension cable provided with
your eye safety filter.
To connect the eye safety filter to the laser, connect the filter plug to the
system as instructed in the appropriate delivery system operator’s manual.
Insert the extension cable plug into the laser system’s appropriate
connection port.
If you are using a fixed eye safety filter, then you must insert an emulation
plug
2
into the laser system’s eye safety filter connection port.
the Laser
Note
The LIO delivery system has an integrated eye safety filter. When
using an LIO inserting an emulation plug is not necessary.
2
Supplied with the Fixed ESF kit.
Warning
