When the switch is released, the automatic stop function of
the overwinding prevention device turns into an operating
state.
While this switch is pressed, the red lamp of the rotating
warning lamp illuminates.
When the winch is hoisted while
the hoisting speed becomes slow, which is not a fault.
[4] TRAVEL MODE SELECTOR SWITCH
Travel with a lifted load is in principle not advised because it is very unstable and involves
danger.
If travel with a lifted load is unavoidably performed, see "OPERATION 3.24 OPERATION
DURING TRAVELLING HOIST " and strictly observe the rated total load, operation method
and travel posture with a lifted load at the time of travel with a lifted load.
Unless these precautions in travell
ing with a lifted load are observed, serious physical
injury may be caused.
When the switch (4) is pressed, the mode can be changed
from the stationary mode to the travel mode enabling travel
with a lifted load.
The display of the machine body illustration on the top
screen changes.
[5] TRAVEL 1ST SPEED/2ND SPEED SELECTOR SWITCH
Be sure to perform loading to and unloading from a trailer at low speed ("set to 1st speed").
While travelling, never perform changing operation of the travel speed selector switch.
• If changing operation of high/low speed (2nd speed - 1st speed) i
travelling, the travel direction may deviate even while travelling in a straight line. Perform
changing operation of travel speed after stopping the machine.
• The rear of the machine body is a blind spot. Be sure to check the rear of the machine
body with a rear view camera before performing backward travel operation.
