Ultra Electronics Card Systems

Rio Pro Maintenance Manual

- 100 -

SECTION 16.8 MOTOR LAYOUT AND PART NUMBERS.

Flipper Unit Motor

(Stepper)

Flipper Card Feed

Motor (Stepper)

Dye-Film Motor

(DC)

Card Feed Motor

(DC)

Print Head Roller

Motor

(Stepper)

Cam Motor

(DC)
