Ultra Electronics Card Systems

Rio Pro Maintenance Manual

- 98 -

SECTION 16.6 DRIVE MECHANISM RIGHT HAND SIDE.

80 Teeth Belt

E9055

115 Teeth Belt

E9056

30 Teeth Pulley

3633-0200-006

RFID PCB

M9500-853/R

30 Teeth Pulley

3633-0200-005

Top Cover Assembly

3652-0150-005

144 Teeth Belt

E9058

H Frame Assembly
