Magicard Rio Pro - Replacing the Print Head; Section 10.3 Replacing the Print Head

Ultra Electronics Card Systems
Rio Pro Maintenance Manual
- 41 -
SECTION 10.3 REPLACING THE PRINT HEAD.
CAUTION The following procedures involve contact with Electrostatic Sensitive Devices. All precautions for
handling Electrostatic Sensitive Devices should be followed at all times, including the use of a grounded
wrist strap.
Start

Switch the
Printer Off !
Remove
Connector
Push backwards
then tilt upward
1
2
Fit the new
Print Head
1
2
Re-connect
the new Print
Head
Press any Button to
switch the
Printer On !
2
