SECTION 17 PRODUCT UPDATES

Rio Pro Printhead Roller Pulley

The Large Drive Pulley is now fitted with a

black Flange to prevent Belt slippage.

Please Note:

The large Drive Pulley Flange is fitted here

(attached at four points).

3652-0145 Large Drive Pulley
