Ultra Electronics Card Systems

Rio Pro Maintenance Manual

- 104 -

Part Numbers:

3633-0100-011 Brush Strip

E9243 Pop Rivet

3633-0403 Modified Wire Loom

Anti Static Brush Strip is fitted

here.

Rio Pro Stepper Motor pulleys are now held in

place by Push-On „Star Washer‟ (P/N

RIO/0465), left side also.
