Ultra Electronics Card Systems
Rio Pro Maintenance Manual
- 32 -
SECTION 9 PRINTER DISPLAY
The front display panel has a text display and 4 push buttons. These buttons act as „soft‟ buttons – i.e. their function
varies depending on the text displayed immediately above each button.
SECTION 9.1 MENU OPTIONS
Press the “Menu” button…
The first menu option will be displayed.
Press the “>” button (where indicated) to
step through each option in the menu…
The following menu options will be displayed:
1 of 6 – Clean rollers
2 of 6 – Test card
3 of 6 – Info
4 of 6 – Hand feed
5 of 6 – Mag self test
6 of 6 – Reset printer
Options 1-6 are explained on Page 32
Off Button
Switches the Printer off.
To switch the Printer ON
again press any Button
Text Display
Menu select
Buttons
